| Frame | ADC12 |
| Impeller | Thermal Plastic，PBT UL 94V-0 |
| Bearing type | Sleeve Bearing & Ball Bearing |
| Lead wires | UL Type or Equivalent |
| Operating Temperature | -10℃-70℃ 35%-85%RH |
| Storage Temperature | -40℃-80℃ 35%-85%RH |
-
-
Listed Model Voltage Frequency Inputpower Current Rated Speed Air Flow Static Pressure Noise Level Weight （VAC） （HZ） (W) (A) (RPM) (CFM) (mmH2O) (dBA) g 1238S110H 110/120 50/60 21/20 0.28/0.26 2700/3100 80/91 4.57/7.62 44/49 480 1238S220H 220/240 50/60 21/20 0.14/0.13 2700/3100 80/91 4.57/7.62 44/49 480 1238B110H 110/120 50/60 21/20 0.28/0.26 2700/3100 80/91 4.57/7.62 44/49 480 1238B220H 220/240 50/60 21/20 0.14/0.13 2700/3100 80/91 4.57/7.62 44/49 480 -
