| Instructions for use： |
|
| Way of working: | S1 |
| Protection level: | IP42 |
| Insulation class: | B |
| Environment temperature: | -30℃~50℃ |
| Application range: |
FAN BLADE Φ172 240~300 m³/h |
| Φ200 360~460m³/h | |
| Φ230 480-680m³/h | |
| Φ250 700~1050m³/h | |
| Φ300 1100~1500m³/h |
-
-
Type Voltage Frequency Pated Input Output Rated current Rated Speed Air volume Fan blade Net weight A B C D E License （V） （HZ） （W） （W） （A） (r/min) (m³/h CFM) (mm) (kg) (mm) (mm) (mm) (mm) (mm) YZF5-13-18 220-240 50/60 20 2 0.14 1300 260 Φ172 0.8 13 12 43 78 - ce ccc RoHS YZF5-13-18 220-240 50/60 25 5 0.20 1300 360 Φ170 0.8 13 12 43 78 - ce ccc RoHS YZF5-13-18 220-240 50/60 30 5 0.20 1550 430 Φ200 0.8 13 12 43 78 - ce ccc RoHS YZF5-13-18 220-240 50/60 33 5 0.20 1550 430 YZF5-13-18 220-240 50/60 35 5 0.20 1550 430 YZF6-13-18 110-120 60 33 6 0.55 1550 430 YZF7-20-18 220-240 50/60 31 7 0.23 1300 480 Φ230 1.1 19 13 44 85 - ce ccc RoHS YZF10-20-18 220-240 50/60 36 10 0.25 1300 500 Φ200 1.1 19 13 44 85 - ce ccc RoHS 220-240 50/60 40 10 0.25 1300 500 Φ230 1.1 19 13 44 85 - ce ccc RoHS 110-120 60 55 10 0.80 1550 620 YZF12-20-18 220-240 50/60 54 12 0.36 1300 720 Φ230 1.1 19 13 44 85 - ce ccc RoHS YZF16-25-18 220-240 50/60 60 16 0.45 1300 1000 Φ250 1.4 25 14 45 92 - ce ccc RoHS YZF18-25-18 110-120 60 70 18 1.01 1550 1050 -
